BT-1 Automatic Warping Machine

Adopt PLC control touch screen, this BT-1 automatic warping machine provides you convenience for your business, especially suit for small and medium productive capacity clients. This type automatic warper is capable of warping various materials including polypropylene fiber, PP fiber, spun polyester thread, low - elastic polyester yarn, high - elastic polyester yarn, cotton yarn, nylon yarn, etc.

Features
  • 1-10 yarns can be started quickly without yarns separating, reducing the steps and increasing the production efficiency by more than 3 times.
  • Automatic operation saves labor cost and the warper is safe and easy to operate.
  • Excellent beam quality through uniform yarn tension, whole process is smooth without yarn crimping, pilling, no garbling.
  • The maximum warp count can be more than 2,000 yards.
Parameters
  • Overall Dimension (L x W x H): 1500 x 620 x 880mm (head)
  • Applicable warp beam (OD x OD): 288x300mm
  • Motor power: 1.1KW
  • Machine warping speed: 100m-300m/min
  • Weight: 110KG
  • Fixed voltage: 20ov-380V (optional)
  • Maximum number of warping strips: 200 beams
  • Maximum number of warping yards: 2000 yards
