High Speed Cord Knitting Machine

High Speed Cord Knitting Machine
High Speed Cord Knitting Machine High Speed Cord Knitting Machine

CO-60 high speed cord knitting machine is specially built for producing medical face mask earloop, featuring a higher production capacity compared to other earloop making machines. It adopts double-sided working structure with PLC system for stepless speed regulating. What’s more, this cord knitting machine is designed with LED lamp, so that operator can easily check the working condition of the machine. Once order is placed, fast delivery can be achieved, we are capable of manufacturing 10 machines within 12-15 days.

Specifications
Model CO-60
Hooks 20x3
Max. Spindle Speed (r/min) 4500
Roller speed (m/min) 2~2.5
Cylinder Inside Dia.(mm) Flat earloop (4mm width) 5.5
Round earloop (3mm diameter) 4.3
Needle Type Flat earloop (4mm width) 12# x 16pcs
Round earloop (3mm diameter) 12# x 6pcs
Daily Output (kg) 180-200
Main Motor Power (kW) 2.2
Gear Motor Power (kW) 0.5
Power Supply 3PH/380V/50HZ
